Oil Filling and Transportation Unit UDM
The UDM unit is designed for pumping, storing, transporting and filling transformers with electrical insulating oil. The unit is supplied with either a manual or electric pump.
| Parameter | Value |
| Vessel volume, liters/gals | 1000/264.2 |
| Input pump capacity, m3/gals. per hour | 1.7/450 |
| Manual output pump max capacity,l/gals.min. max | 30/7.8 |
| Nominal power, kW | 2.2 |
| Electric power supply parameters | fully customizable |
| Dimensions, mm/ft, max | |
| • length• width• height | 3575/141”
1805/71.1” 1705/67.1” |
| Weight, kg/lbs, max | 850/1,878.5 |
- versatility (pumping, storage, transportation and adding of transformer oil);
- mobility;
- simple operation and servicing.
