Zeolite Regeneration Units BRZ

    GlobeCore

    LEAVE A MESSAGE






    The BRZ regeneration unit is designed to restore the performance of the CP-260 sorbent cartridges used in drying dielectric insulating oil. The BRZ unit regenerates the cartridges by hot air to purge and clean the cartridges of excess moisture. The BRZ unit can be used by any facility using the CP-260 cartridges for drying of lubricating and insulating oils.

    Parameter Value
    Heater power, kW 10.8
    Cooler blower drive power, kW 0.75
    Nominal power, kW 13.2
    Zeolite drying mode parameters
    • air blower throughput, m3/minute
    		 2.3
    • hot air temperature, oC/F
    		 250/483
    Vacuum pulling mode parameters
    • evacuation rate, l/second
    		 6.6
    • residual pressure,mbar (mPa)
    		 250
    Dimensions, mm:
    • length
    		 1100/3’3’’
    • width
    		 650/2’2’’
    • height
    		 1250/4’1’’
    Weight, kg 220/486.2

    • restoration of initial zeolite parameters;
    • other sorbents can be regenerated, such as silica gel;
    • can be used with a CMM-260C unit or alone;
    • compact size and mobility;
    • simple operation and servicing.
